小白第一次尝试用mindspore去跑一遍《RNN实现情感分类》。

这里教程案例中的情感分类是根据一段或一句话，让机器认知出是什么类型的情感，给出对应分类的标签。给予的数据集是IMDB影评数据集，其中有输入也有输出，所以是有监督学习；这里既然是人的自然语言，那不可缺少的就是将其转化为机器可识别的语言，所以预训练词向量编码也要同步进行。这里案例中选用的是Glove词向量（也不懂有啥好处，后续再研究）。

# 指定保存路径为 `home_path/.mindspore_examples`
cache_dir = Path.home() / '.mindspore_examples'

def http_get(url: str, temp_file: IO):
    """使用requests库下载数据，并使用tqdm库进行流程可视化"""
    req = requests.get(url, stream=True)
    content_length = req.headers.get('Content-Length')
    total = int(content_length) if content_length is not None else None
    progress = tqdm(unit='B', total=total)
    for chunk in req.iter_content(chunk_size=1024):
        if chunk:
            progress.update(len(chunk))
            temp_file.write(chunk)
    progress.close()

def download(file_name: str, url: str):
    """下载数据并存为指定名称"""
    if not os.path.exists(cache_dir):
        os.makedirs(cache_dir)
    cache_path = os.path.join(cache_dir, file_name)
    cache_exist = os.path.exists(cache_path)
    if not cache_exist:
        with tempfile.NamedTemporaryFile() as temp_file:
            http_get(url, temp_file)
            temp_file.flush()
            temp_file.seek(0)
            with open(cache_path, 'wb') as cache_file:
                shutil.copyfileobj(temp_file, cache_file)
    return cache_path

开始下载数据集，并下载影评数据集到当前目录下：

imdb_path = download('aclImdb_v1.tar.gz', 'https://mindspore-website.obs.myhuaweicloud.com/notebook/datasets/aclImdb_v1.tar.gz')
imdb_path

解压完数据集后，其中就有train和test两部分，对其进行数据清洗，去除非必要喂给机器的：

import re
import six
import string
import tarfile

class IMDBData():
    """IMDB数据集加载器

    加载IMDB数据集并处理为一个Python迭代对象。

    """
    label_map = {
        "pos": 1,
        "neg": 0
    }
    def __init__(self, path, mode="train"):
        self.mode = mode
        self.path = path
        self.docs, self.labels = [], []

        self._load("pos")
        self._load("neg")

    def _load(self, label):
        pattern = re.compile(r"aclImdb/{}/{}/.*\.txt$".format(self.mode, label))
        # 将数据加载至内存
        with tarfile.open(self.path) as tarf:
            tf = tarf.next()
            while tf is not None:
                if bool(pattern.match(tf.name)):
                    # 对文本进行分词、去除标点和特殊字符、小写处理
                    self.docs.append(str(tarf.extractfile(tf).read().rstrip(six.b("\n\r"))
                                         .translate(None, six.b(string.punctuation)).lower()).split())
                    self.labels.append([self.label_map[label]])
                tf = tarf.next()

    def __getitem__(self, idx):
        return self.docs[idx], self.labels[idx]

    def __len__(self):
        return len(self.docs)


imdb_train = IMDBData(imdb_path, 'train')
len(imdb_train)

运行出来train数据集大小是25000。

调用mindspore.dataset中的GeneratorDataset接口进行封装，得到一个对象：

import mindspore.dataset as ds

def load_imdb(imdb_path):
    imdb_train = ds.GeneratorDataset(IMDBData(imdb_path, "train"), column_names=["text", "label"], shuffle=True)
    imdb_test = ds.GeneratorDataset(IMDBData(imdb_path, "test"), column_names=["text", "label"], shuffle=False)
    return imdb_train, imdb_test

imdb_train, imdb_test = load_imdb(imdb_path)
imdb_train

接下来是将数据集结合预训练词向量Glove，先处理Glove,将其数据格式转换，按照一个单词一个词向量的形式，再配比权重，补上可能与数据集结合时单词可能不存在词向量的占位符。

import zipfile
import numpy as np

def load_glove(glove_path):
    glove_100d_path = os.path.join(cache_dir, 'glove.6B.100d.txt')
    if not os.path.exists(glove_100d_path):
        glove_zip = zipfile.ZipFile(glove_path)
        glove_zip.extractall(cache_dir)

    embeddings = []
    tokens = []
    with open(glove_100d_path, encoding='utf-8') as gf:
        for glove in gf:
            word, embedding = glove.split(maxsplit=1)
            tokens.append(word)
            embeddings.append(np.fromstring(embedding, dtype=np.float32, sep=' '))
    # 添加 <unk>, <pad> 两个特殊占位符对应的embedding
    embeddings.append(np.random.rand(100))
    embeddings.append(np.zeros((100,), np.float32))

    vocab = ds.text.Vocab.from_list(tokens, special_tokens=["<unk>", "<pad>"], special_first=False)
    embeddings = np.array(embeddings).astype(np.float32)
    return vocab, embeddings

glove_path = download('glove.6B.zip', 'https://mindspore-website.obs.myhuaweicloud.com/notebook/datasets/glove.6B.zip')
vocab, embeddings = load_glove(glove_path)
len(vocab.vocab())

最后进行数据预处理的最后阶段：将数据集中每个单词处理成index_id,方便与词向量对应；再把每个文本序列统一长度。

import mindspore as ms

lookup_op = ds.text.Lookup(vocab, unknown_token='<unk>')
pad_op = ds.transforms.PadEnd([500], pad_value=vocab.tokens_to_ids('<pad>'))
type_cast_op = ds.transforms.TypeCast(ms.float32)

imdb_train = imdb_train.map(operations=[lookup_op, pad_op], input_columns=['text'])
imdb_train = imdb_train.map(operations=[type_cast_op], input_columns=['label'])

imdb_test = imdb_test.map(operations=[lookup_op, pad_op], input_columns=['text'])
imdb_test = imdb_test.map(operations=[type_cast_op], input_columns=['label'])

imdb_train, imdb_valid = imdb_train.split([0.7, 0.3])

imdb_train = imdb_train.batch(64, drop_remainder=True)
imdb_valid = imdb_valid.batch(64, drop_remainder=True)

接下来开始构建训练模型，把每个index_id对应的词向量为给RNN网络进行提取特征，最后再通过全连接层输出分类标签。

import math
import mindspore as ms
import mindspore.nn as nn
import mindspore.ops as ops
from mindspore.common.initializer import Uniform, HeUniform

class RNN(nn.Cell):
    def __init__(self, embeddings, hidden_dim, output_dim, n_layers,
                 bidirectional, dropout, pad_idx):
        super().__init__()
        vocab_size, embedding_dim = embeddings.shape
        self.embedding = nn.Embedding(vocab_size, embedding_dim, embedding_table=ms.Tensor(embeddings), padding_idx=pad_idx)
        self.rnn = nn.LSTM(embedding_dim,
                           hidden_dim,
                           num_layers=n_layers,
                           bidirectional=bidirectional,
                           dropout=dropout,
                           batch_first=True)
        weight_init = HeUniform(math.sqrt(5))
        bias_init = Uniform(1 / math.sqrt(hidden_dim * 2))
        self.fc = nn.Dense(hidden_dim * 2, output_dim, weight_init=weight_init, bias_init=bias_init)
        self.dropout = nn.Dropout(1 - dropout)

    def construct(self, inputs):
        embedded = self.dropout(self.embedding(inputs))
        _, (hidden, _) = self.rnn(embedded)
        hidden = self.dropout(ops.concat((hidden[-2, :, :], hidden[-1, :, :]), axis=1))
        output = self.fc(hidden)
        return output

下面选择损失函数nn.BCEWithLogitsLoss和优化器nn.Adam：

hidden_size = 256
output_size = 1
num_layers = 2
bidirectional = True
dropout = 0.5
lr = 0.001
pad_idx = vocab.tokens_to_ids('<pad>')

net = RNN(embeddings, hidden_size, output_size, num_layers, bidirectional, dropout, pad_idx)
loss = nn.BCEWithLogitsLoss(reduction='mean')
optimizer = nn.Adam(net.trainable_params(), learning_rate=lr)

然后构建循环分批训练的逻辑：

def train_one_epoch(model, loss_fn, optimizer, train_dataset, epoch=0):
    def forward_fn(data, label):
        logits = model(data)
        loss = loss_fn(logits, label)
        return loss

    grad_fn = ms.value_and_grad(forward_fn, None, optimizer.parameters)

    def train_step(data, label):
        loss, grads = grad_fn(data, label)
        loss = ops.depend(loss, optimizer(grads))
        return loss

    model.set_train()
    total = train_dataset.get_dataset_size()
    loss_total = 0
    step_total = 0
    with tqdm(total=total) as t:
        t.set_description('Epoch %i' % epoch)
        for i in train_dataset.create_tuple_iterator():
            loss = train_step(*i)
            loss_total += loss.asnumpy()
            step_total += 1
            t.set_postfix(loss=loss_total/step_total)
            t.update(1)

主要是正向计算和反向传播进行调整权重，再返回loss，从而降低loss。

进行评估指标，看是否符合预期：

def binary_accuracy(preds, y):
    """
    计算每个batch的准确率
    """

    # 对预测值进行四舍五入
    rounded_preds = np.around(ops.sigmoid(preds).asnumpy())
    correct = (rounded_preds == y).astype(np.float32)
    acc = correct.sum() / len(correct)
    return acc


def evaluate(model, test_dataset, criterion, epoch=0):
    total = test_dataset.get_dataset_size()
    epoch_loss = 0
    epoch_acc = 0
    step_total = 0
    model.set_train(False)

    with tqdm(total=total) as t:
        t.set_description('Epoch %i' % epoch)
        for i in test_dataset.create_tuple_iterator():
            predictions = model(i[0])
            loss = criterion(predictions, i[1])
            epoch_loss += loss.asnumpy()

            acc = binary_accuracy(predictions, i[1])
            epoch_acc += acc

            step_total += 1
            t.set_postfix(loss=epoch_loss/step_total, acc=epoch_acc/step_total)
            t.update(1)

    return epoch_loss / total

这里是二分类问题的所以评估比较简单。

最后终于要开始模型训练与保存了

num_epochs = 5
best_valid_loss = float('inf')
ckpt_file_name = os.path.join(cache_dir, 'sentiment-analysis.ckpt')

for epoch in range(num_epochs):
    train_one_epoch(net, loss, optimizer, imdb_train, epoch)
    valid_loss = evaluate(net, imdb_valid, loss, epoch)

    if valid_loss < best_valid_loss:
        best_valid_loss = valid_loss
        ms.save_checkpoint(net, ckpt_file_name)

我的本地运行结果如下：

 用GPU训练的，速度快点，别的可能要等好久了。

用测试集试一下正确率如何：

param_dict = ms.load_checkpoint(ckpt_file_name)
ms.load_param_into_net(net, param_dict)

imdb_test = imdb_test.batch(64)
evaluate(net, imdb_test, loss)

结果如图：



0.64，对于应用来说有些低了。

再本地测试一下效果：

predict_sentiment(net, vocab, "This film is terrible")

predict_sentiment(net, vocab, "This film is great")

predict_sentiment(net, vocab, "This movie makes people cry")

Negative
Positive
Positive

给的案例运行结果倒是没啥问题，我自己写的一句话确实分析错误了。后续我再优化多跑几遍，提升一下准确率再试试。
